Description:

1. Metal construction with durable and solid design

2. All-in-one On-camera monitor/Field monitor, available with both HD-SDI and DVI (HDMI w/adapter);

3. Variety of battery plate types: V-mount, Anton Bauer, 7.2V small plate;

4. Three way power supply with 12V DC IN: AC-DC adapter / Battery / Power adapter cable from camera directly.

Advanced features:

Embedded audio(SDI), Aspect ratio, Overscan, Underscan, Safe Markers, Color Temperature settings, User presets, TALLY, Built-in speaker and more.

Standard Accessories:

Camera mount adapter, AC-DC adapter, DC power cable(from camera power), SDI cable, audio cable, carrying case.

Specification

Screen size	8.4inches
Resolution	800 (H) x 600(V)
Dot pitch	0.213(H) x 0.213 (V) mm
Display ratio	16:9 / 4:3
Brightness	350cd per 1 square meter
Contrast	320:1
Response time	7 ms
Viewing angle	L 80-degree /R 80-degree /U 45-degree /D 80-degree
Input voltage	DC 12V
Power consumption	Lower than 14W
Monitor size	L 223 x H 192 x D 52 mm
Weight	1.7 kg

Inputs & Functions

Composite in	BNC x 1line
Component(Y/Pb/Pr)in	BNC x 1line
SD-SDI in	BNC x 1line
DVI in	1line
Audio in	RCA x 1line(dual channel)
Audio monitoring	Speakers 2 x 0.5W(8 ohm)
SDI embedded audio	PPM / UV
Composite out	BNC x 1line
Component(Y/Pb/Pr)out	BNC x 1line
SD-SDI out	BNC x 1line
TALLY	Red / green two color
