Description:

1. All-in-one On-camera monitor, with HDMI;

2. Smart sun cover, convertible and removable;

3. Variety of user-replaceable battery plate;

4. Three way power supply with 12V DC IN: AC-DC adapter / Battery / Power adapter cable from camera directly.

Advanced features:

Aspect ratio, Over scan, Under scan, Safe Markers, Color Temperature settings, User presets, TALLY, Built-in speaker, headphone and more.

Standard Accessories:

1. Smart Sun cover, Camera mount adapter, AC-DC adapter, DC power cable (from camera power), video cable, carrying case.
2. Director bag (Optional)

Specification

Screen size	7inches
Resolution	800 (H) x 480(V)
Dot pitch	0.0635(H) x 0.1905(V) mm
Display ratio	16:9 / 4:3
Brightness	300cd per 1 square meter
Contrast	500:1
Response time	10 ms
Viewing angle	L 70-degree /R 70-degree /U 50-degree /D 70-degree
Input voltage	DC 12V
Power consumption	Lower than 11W
Monitor size	L 207 x H 147 x D 44 mm
Weight	0.8 kg

Inputs & Functions

Composite in	BNC x 1line
Component(Y/Pb/Pr)in	BNC x 1line
HDMI in	1line
Audio in	RCA x 1line(dual channel)
Audio monitoring	Front speakers 0.5W(8 ohm)
Composite out	BNC x 1line
Component(Y/Pb/Pr)out	BNC x 1line
TALLY	Red / green two color
