Description:
1. All-in-one On-camera monitor, with both SDI and HDMI;
2. Smart sun cover, convertible and removable;
3. Variety of user-replaceable battery plate;
4. Three way power supply with 12V DC IN: AC-DC adapter / Battery / Power adapter cable from camera directly.
Advanced features:
Embedded audio(SDI), Aspect ratio, Over scan, Under scan, Safe Markers, Color Temperature settings, User presets, TALLY, Built-in speaker, headphone and more.
Standard Accessories:
1. Smart Sun cover, Camera mount adapter, AC-DC adapter, DC power cable(from camera power), SDI cable, audio cable, carrying case. 2. Director bag (Optional)
Specification
Screen size |
7inches |
Resolution |
800 (H) x 480(V) |
Dot pitch |
0.0635(H) x 0.1905(V) mm |
Display ratio |
16:9 / 4:3 |
Brightness |
300cd per 1 square meter |
Contrast |
500:1 |
Response time |
10 ms |
Viewing angle |
L 70-degree /R 70-degree /U 50-degree /D 70-degree |
Input voltage |
DC 12V |
Power consumption |
Lower than 11W |
Monitor size |
L 207 x H 147 x D 44 mm |
Weight |
0.8 kg |
Inputs & Functions
Composite in |
BNC x 1line |
Component(Y/Pb/Pr)in |
BNC x 1line |
SD-SDI in |
BNC x 1line |
HDMI in |
1line |
Audio in |
RCA x 1line(dual channel) |
Audio monitoring |
Front speakers 0.5W(8 ohm) |
SDI embedded audio |
PPM / UV |
Composite out |
BNC x 1line |
Component(Y/Pb/Pr)out |
BNC x 1line |
SD-SDI out |
BNC x 1line |
TALLY |
Red / green two color |
|
