Characteristics:
TL-480HD series is 4.8 inches high definition LCD monitor which is mainly used in high-end video shooting such as Canon 5D/7D etc. This series monitors adopts SHARP/NEC/SAMSUNG original professional LCD panel and international famous brand CANARE/BNC connector to transmit the SD/HD-SDI signal to make sure the HD signal quality. The monitor can display true color gamut of original signal to guarantee correcting color temperature accurately. TL-480HD series has four models that are TL-480HD, TL-480HDA, TL-480HDB and TL-480HDC. The appearance (product specification) of these models is same, but the input format and function are different.
Product specification:
|
Model |
TL-480HD/TL-480HDA/TL-480HDB/TL-480HDC |
|
Screen size |
4.8inches |
|
Resolution |
800(H) x 480(V) |
|
Pixel Pitch |
0.130(H) x 0.130(V)mm |
|
Display Ratio |
16:9/4:3(switch) |
|
Brightness |
500cd per 1 square meter |
|
Contrast Ratio |
800:1 |
|
Viewing Angle |
Left and right 160 degrees / up and down 160 degrees |
|
Input |
AC 220V |
|
Power |
Lower than 9W |
|
Response Time |
10ms |
|
Monitor external size |
147 x 100 x 48 (mm) |
|
Weight |
0.5kg |
Input format & function:
|
Model |
TL-480HDC |
TL-480HDB |
TL-480HDA |
TL-480HD |
|
Composite in
(BNC x 1line) |
Yes |
Yes |
Yes |
--- |
|
SD-SDI in
(BNC x 1line) |
Yes |
Yes |
--- |
--- |
|
HD-SDI in
(BNC x 1line) |
Yes |
Yes |
--- |
--- |
|
HDMI in
(1line) |
Yes |
Yes |
Yes |
Yes |
|
SDI embedded audio
(PPM/UV) |
Yes |
Yes |
--- |
--- |
|
Composite out
(BNC x 1line) |
Yes |
Yes |
Yes |
--- |
|
HDMI out
(1 line) |
Yes |
Yes |
Yes |
--- |
|
SD-SDI out
(BNC x 1line) |
Yes |
Yes |
--- |
--- |
|
HD-SDI out
(BNC x 1line) |
Yes |
Yes |
--- |
--- |
|
Loop from HDMI to SDI (built-in converter) |
Yes |
--- |
--- |
--- |
Standard Accessories:
Smart Sun cover, Camera mount adapter, AC-DC adapter, HDMI cable.
HDMI Lock adapter (Optional), Battery plate (optional).
|
