Details:
Model |
TL-400NP-4 |
Description |
analogue signal LCD monitor with rack-mount |
Screen size |
4inches |
Resolution |
960(H) x 234(V) |
Pixel Pitch |
0.085(H) x 0.264(V)mm |
Display Ratio |
16:9/4:3(switch) |
Brightness |
250cd per 1 square meter |
Contrast Ratio |
350:1 |
Viewing Angle |
Left and right 110 degrees / up and down 50 degrees |
Input |
DC 12V |
Power |
Lower than 16W |
Response Time |
15ms |
Monitor external size |
482 x 89 x 90mm (2U) |
Weight |
1.6kg |
Composite in |
BNC x 4line |
Composite out |
BNC x 4line |
Characteristics:
TL-400NP-4 is 4 inches LCD monitor adopt analogue input monitor with rack mount. Backlight technology use high-light LED for making uniform brightness on display. The 4pcs of 4inches LCD in 2U and special wheel type potentiometer bring comfortable adjustment of analog quantity. This model is very suitable for TV project. The standard accessories contains mounting bracket, set screws, AC adapter, AC power cable, video cable, audio cable.
|
