Details:

Model	SL-C6000
Description	HMI light contains 1pc 6000W light, 1pc electronic ballast, 1pc cable (7m or 15m) for connecting ballast and light, 1pc hard case
Power	6000W
Color temperature	5600K
Lamp holder	GY38
Light size	930 x700 x615 (mm)
Lens diameter	420mm, low expansion borosilicate Fresnel Lens
Light weight	38kg

Illumination:

Spot 6-degree
Illumination	42500Lux/10m	18890Lux15m	10625Lux/20m
Spot diameter	1.0m	1.6m	2.1m
Flood 58-degree
Illumination	2650Lux/10m	1178Lux/15m	663Lux/20m
Spot diameter	11.1m	16.6m	22.2m

Characteristics:

Const HMI light SL-C6000 is compact daylight spotlight with Const electronic ballast SL-EB6000. The light SL-C4000 adopt bulb single-ended assemble and disassemble technology that reduce light size and weight while guaranteeing nice optical performance. Const especially select thermoplastic light out-shell and antirust/anticorrosion Aluminum inner-shell to increase Const HMI light's mechanical strength and corrosion resistance. Const electronic ballast SL-EB6000 can auto-identify and drive metallic halide lamp. Besides, our SL-EB6000 can possess high power density. Use Const HMI light with Const electronic ballast can provide high-efficiency illumination and uniform beam. This model is very appropriate for both indoor and outdoor environment.

Electronic ballast specification

Model	SL-EB6000W
Input voltage	AC 180~250V
Input frequency	50/60Hz
Input current	38~28A
Efficiency	93%
Power factor	0.98
Output power	6000W
Dimension	243x358x450 (mm)
Weight	25Kg
