Details:

Model	SL-C4000
Description	HMI light contains 1pc 4000W light, 1pc electronic ballast, 1pc cable (7m or 15m) for connecting ballast and light, 1pc hard case
Power	4000W
Color temperature	5600K
Lamp holder	GY38
Light size	790 x610 x480 (mm)
Lens diameter	300mm, low expansion borosilicate Fresnel Lens
Light weight	25kg

Illumination:

Spot 7-degree
Illumination	21250Lux/10m	9445Lux15m	5313Lux/20m
Spot diameter	1.2m	1.8m	2.4m
Flood 60-degree
Illumination	1750Lux/10m	778Lux/15m	438Lux/20m
Spot diameter	11.5m	17.3m	23m

Characteristics:

Const HMI light SL-C4000 is compact daylight spotlight with Const electronic ballast SL-EB4000. The light SL-C4000 adopt bulb single-ended assemble and disassemble technology that reduce light size and weight while guaranteeing nice optical performance. Const especially select thermoplastic light out-shell and antirust/anticorrosion Aluminum inner-shell to increase Const HMI light's mechanical strength and corrosion resistance. Const electronic ballast SL-EB4000 can auto-identify and drive metallic halide lamp. Besides, our SL-EB4000 can possess high power density. Use Const HMI light with Const electronic ballast can provide high-efficiency illumination and uniform beam. This model is very appropriate for both indoor and outdoor environment.

Electronic ballast specification

Model	SL-EB4000/6000W
Input voltage	AC 180~250V
Input frequency	50/60Hz
Input current	38~28A / 24A~19A
Efficiency	93%
Power factor	0.98
Output power	4000W/6000W
Dimension	243x358x450 (mm)
Weight	25Kg
