Details:
Model |
SL-C2500 |
Description |
HMI light contains 1pc 2500W light, 1pc electronic ballast, 1pc cable (7m or 15m) for connecting ballast and light, 1pc hard case |
Power |
2500W |
Color temperature |
5600K |
Lamp holder |
GY38 |
Light size |
750 x510 x 390 (mm) |
Lens diameter |
250mm, low expansion borosilicate Fresnel Lens |
Light weight |
19.5kg |
Illumination:
Spot 7-degree |
Illumination |
18520Lux/9m |
10410Lux12m |
6670Lux/15m |
Spot diameter |
1.1m |
1.5m |
1.8m |
Flood 60-degree |
Illumination |
1545Lux/9m |
870Lux/12m |
550Lux/15m |
Spot diameter |
10.4m |
13.9m |
17.3m |
Characteristics:
Const HMI light SL-C2500 is compact daylight spotlight with Const electronic ballast SL-EB2500. The light SL-C2500 adopt bulb single-ended assemble and disassemble technology that reduce light size and weight while guaranteeing nice optical performance. Const especially select thermoplastic light out-shell and antirust/anticorrosion Aluminum inner-shell to increase Const HMI light's mechanical strength and corrosion resistance. Const electronic ballast SL-EB2500 can auto-identify and drive metallic halide lamp. Besides, our SL-EB2500 can possess high power density. Use Const HMI light with Const electronic ballast can provide high-efficiency illumination and uniform beam. This model is very appropriate for both indoor and outdoor environment.
Electronic ballast specification
Model |
SL-EB2500/4000W |
Input voltage |
AC 90~250V |
Input frequency |
50/60Hz |
Input current |
24~19A |
Efficiency |
93% |
Power factor |
0.98 |
Output power |
2500W/4000W power automatic adjustment |
Dimension |
243x358x450 (mm) |
Weight |
17Kg |
|
