Details:

Model	SL-C1200
Description	HMI light contains 1pc 1200W light, 1pc electronic ballast, 1pc cable (7m or 15m) for connecting ballast and light, 1pc hard case
Power	1200W
Color temperature	5600K
Lamp holder	GY38
Light size	590 x 420 x 330 (mm)
Lens diameter	175mm, low expansion borosilicate Fresnel Lens
Light weight	11.5kg

Illumination:

Spot 6-degree
Illumination	46880Lux/4m	20800Lux/6m	11700Lux/8m
Spot diameter	0.4m	0.6m	0.8m
Flood 58-degree
Illumination	3125Lux/4m	1390Lux/6m	780Lux/8m
Spot diameter	4.4m	6.7m	8.9m

Characteristics:

Const HMI light SL-C1200 is compact daylight spotlight with Const electronic ballast SL-EB1200. The light SL-C1200 adopt bulb single-ended assemble and disassemble technology that reduce light size and weight while guaranteeing nice optical performance. Const especially select thermoplastic light out-shell and antirust/anticorrosion Aluminum inner-shell to increase Const HMI light's mechanical strength and corrosion resistance. Const electronic ballast SL-EB1200 can auto-identify and drive metallic halide lamp. Besides, our SL-EB1200 can possess high power density. Use Const HMI light with Const electronic ballast can provide high-efficiency illumination and uniform beam. This model is very appropriate for both indoor and outdoor environment.

Electronic ballast specification

Model	SL-EB575/1200W
Input voltage	AC 90~125V, AC 180~250V
Input frequency	50/60Hz
Input current	25~18A/13-9A
Efficiency	93%
Power factor	0.68
Output power	575W/1200W power automatic selection
Dimension	200x150x300 (mm)
Weight	7Kg
