Details:
Model |
SL-C575 |
Description |
HMI light contains 1pc 575W light, 1pc electronic ballast, 1pc cable (7m or 15m) for connecting ballast and light, 1pc hard case |
Power |
575W |
Color temperature |
5600K |
Lamp holder |
GY22 |
Light size |
510 x 320 x 265 (mm) |
Lens diameter |
130mm, low expansion borosilicate Fresnel Lens |
Light weight |
7.5kg |
Illumination:
Spot 9-degree |
Illumination |
15300Lux/4m |
9800Lux/5m |
6800Lux/6m |
Spot diameter |
0.6m |
0.7m |
0.8m |
Flood 60-degree |
Illumination |
1875Lux/2m |
1200Lux/3m |
833Lux/4m |
Spot diameter |
4.6m |
5.8m |
6.9m |
Characteristics:
Const HMI light SL-C575 is compact daylight spotlight with Const electronic ballast SL-EB575. The light SL-C575 adopt bulb single-ended assemble and disassemble technology that reduce light size and weight while guaranteeing nice optical performance. Const especially select thermoplastic light out-shell and antirust/anticorrosion Aluminum inner-shell to increase Const HMI light's mechanical strength and corrosion resistance. Const electronic ballast SL-EB575 can auto-identify and drive metallic halide lamp. Besides, our SL-EB575 can possess high power density. Use Const HMI light with Const electronic ballast can provide high-efficiency illumination and uniform beam. This model is very appropriate for both indoor and outdoor environment.
Electronic ballast specification
Model |
SL-EB575/1200W |
Input voltage |
AC 90~125V, AC 180~250V |
Input frequency |
50/60Hz |
Input current |
25~18A/13-9A |
Efficiency |
93% |
Power factor |
0.68 |
Output power |
575W/1200W power automatic selection |
Dimension |
200x150x300 (mm) |
Weight |
7Kg |
|
