Details:

Model	SL-C200
Description	HMI light contains 1pc 200W light, 1pc electronic ballast, 1pc cable (7m or 15m) for connecting ballast and light, 1pc hard case
Power	200W
Color temperature	5600K
Lamp holder	GY9.5
Light size	325 x 225 x 195 (mm)
Lens diameter	112mm, low expansion borosilicate Fresnel Lens
Light weight	4kg

Illumination:

Spot 9-degree
Illumination	16875Lux/2m	7500Lux/3m	4220Lux/4m
Spot diameter	0.3m	0.5m	0.6m
Flood 50-degree
Illumination	2520Lux/2m	1120Lux/3m	630Lux/4m
Spot diameter	1.9m	2.8m	3.7m

Characteristics:

Const HMI light SL-C200 is compact daylight spotlight with Const electronic ballast SL-EB200. The light SL-C200 adopt bulb single-ended assemble and disassemble technology that reduce light size and weight while guaranteeing nice optical performance. Const especially select thermoplastic light out-shell and antirust/anticorrosion Aluminium inner-shell to increase Const HMI light's mechanical strength and corrosion resistance. Const electronic ballast SL-EB200 can auto-identify and drive metallic halide lamp. Besides, our SL-EB200 can possess high power density. Use Const HMI light with Const electronic ballast can provide high-efficiency illumination and uniform beam. This model is very appropriate for both indoor and outdoor environment.

Electronic ballast specification

Model	SL-EB200
Input voltage	AC 90~125V, AC 180~250V
Input frequency	50/60Hz
Input current	2~1.6A
Efficiency	93%
Power factor	0.68
Output power	200W
Dimension	165x135x235 (mm)
Weight	3Kg
